UT70D

UNI-T UT70D Modern Digital Multi-Purpose Meters

UT70D

Modern Digital Multi-Purpose Meters

SPECIFICATIONS

Basic Functions	Range	Best Accuracy
DC Voltage	80mV/800mV/8V/80V/800V/1000V	(0.05%+10)
AC Voltage	800mV/8V/80V/800V/1000V	(0.8%+20)
DC Current	80mA/800mA/8A/10A	(0.2%+40)
AC Current	80mA/800mA/8A/10A	(0.5%+40)
Resistance	800W/8kW/80kW/800kW/8MW/80MW	(0.3%+40)
Conductance	80nS	(2%+120)
Capacitance	1nF/10nF/100nF/1mF/10mF/100mF	(2%+3)
Frequency	1kHz/10kHz/100kHz/1MHz	(0.02%+1)
Duty Cycle	1%~99.9%
Special Functions
Fused 10A Range
Auto Ranging
Diode
Continuity Buzzer
True RMS	AC
Peak/Min/Max
Max/Min/Avg
Relative Mode
Auto Data Hold
RS232C
Display Backlight
Full Icon Display
Sleep Mode
Low Battery Display
Input Impedance for DC Voltage Measurement	10MW
Max Display	79999 (frequency measurement counts 99999)
Analog Bar Graph

GENERAL CHARACTERISTICS

Power	9V Battery (6F22) (**NOT include Battery)
LCD Size	62 x 53mm
Product Colour	UT70D-Grey, Holster - Red
Product Net Weight	600g (including holster)
Product Size	195 x 90 x 40mm
Standard Accessories	Test Lead, English Manual, Test Clip, RS232C Interface Cable, Software, Holster
Optional Accessories*	Clip-On Test Lead Light (UT-TL), Built-In Test Lead Light (UT-L1), Built-In Test Lead Light Plus (UT-L2), Carrying Bag
