BJ9900
BAOJIE BJ9900 Dual Band 136-174/400-470MHZ Transceiver
Product Description:
1. DTMF Signaling
2. Multiple Scan Modes
3. CTCSS/ DCS
Main Functions:
| Frequency range: 136-174/400-470MHz |
| Output Power: VHF:40W/UHF:35W |
| 128 memory channels |
| Dual frequency display |
| DTMF signaling system |
| 50 Groups CTCSS and 105 Groups DCS |
| Wide (25KHz) and Narrow (12.5KHz) selectable |
| Setting FM radio |
| All calls, group calls and selective calls |
| Inspection, Monitor, Stun and Kill |
| Communication through repeater |
| U/V inter-band communication |
| Distant urgency alarm |
| ANI code switch |
| Busy channel lockout |
| 3 kinds of scan mode |
| Mute mode |
| DTMF sidetone switch |
| Weight About: 2075g |
| Dimension: 140*41.5*168mm (projection not included) |
|
Main Function:
|
|
- VHF/UHF dual reception
- Front panel switches & controls
- Compandor
- DTMF encode/decode(8 groups selectable)
- 7 kinds of backlight selectable
- Cross band repeater capability
- Input frequency directly through MIC
|
- FM radio built-in
- 4 kinds of burst tone selectable
(1000Hz/1450Hz/1750Hz/2100Hz)
- Large LCD display
- Air - band receiving
- 1200/9600 bps (B type)
- CTCSS&DCS Encode/Decode
|
|
Specification:
|
|
frequency range: 109-136 (RX only); 136-174MHz(RX/TX); 400-470MHz(RX/TX)
Air band (RX only): AM109-135.995MHz
Memory channels: 128
Bandwidth Wide: 25KHz
Narrow: 12.5KHz
PLL channel stepping: 5/ 6.25/ 10/ 12.5/ 25 KHz
Operating voltage: 13.8VDC+/-15%
Current drain Standby: Less than0.4A
Transmit: Less than 8.0A
Operate temperature range: –20°C-+60°C
Weight: 1,200g
Dimensions: 168*41.5*140mm
|
|
Transmitter
|
Receiver
|
|
RF output power
VHF 40W/20W(144MHz)
UHF 35W/20W(440MHz)
Spurious and harmonics: 70dB
Modulation Wide:16K0F3E
Narrow: 11K0F3E
FM Modulation Noise: Wide:45dB Narrow: 40dB
Audio distortion: Less than 3%
Frequency Stability :+/-2.5ppm
|
Sensitivity(12dB SINAD) Wide:0.18uV Narrow:0.22 uV
Selectivity Wide:70 dB Narrow:60dB
Intermodulation Wide:70 dB Narrow:60dB
Spurious response: 75dB
Audio power output: 2.0W/8Ω
Frequency Stability: +/-2.5ppm
|
| |
|
|
**本機語言是英語設定，無法轉為中文
***所有貨品更改規格,或與說明書不乎,不另外通知,以收貨標準為準.
|
|
|
- 1 x BAOJIE BJ9900 VHF/UHF 136-174/400-470MHZ
- 1 x Microphone
- 1 x DC Power Cable
- 1 x Mounting Bracket
- 1 x Microphone Hanger
- 1 x Screw Set
- 1 x English Manual
