TH9000V

TYT TH-9000 VHF 136-174Mhz Mobile Radio

Main Funciton:

■  Frequency Range:   VHF:136-174MHz
■  Output Power:        VHF: 10W/25W/60W
■  1750Hz Tone	■  CTCSS/DCS setting & scanning
■  0-9 SQL grade setting	■  Frequency/Channel scanning
■  High/Mid/Low power selectable	■  Voice compander
■  Repeater offset shift	■  Keypad lock function
■  Contact book	■  Battery voltage display
■  DTMF/2 tone/5 tone	■  ANI ID
■  Remote kill/ stun/ activate/ revive	■  Emergency alarm
■  Wide/Narrow band setting	■  TX inhibit
■  Busy Channel Lock-Out	■  Channel name editing
■  Reverse frequency	■  Talk around
	■  Voice prompt
■  Time-out Timer	■  Auto Power off
■  VFO step setting:5/6.25/10/12.5/20/25/50kHz

Specifications:

Item Number	TH-9000
General
Frequency Range	136-174MHz
Channel Capacity	200
Channel Spacing	5/6.25/8.33/10/12.5/15/20/25/30/50KHz
Frequency Stability	2.5ppm
Operating Temperature	-20℃ ~ + 60℃
Operating Voltage	13.8V DC ± 15%
Dimension(HxWxD)	145mm x190mm x47mm
Weight(with bracket)	1200g
Receiver
Reference Sensitivity	0.25V / 0.35V
Operating Bandwidth	60dB@12.5KHz /70dB@25KHz
Adjacent Channel Selectivity	60dB@12.5KHz 70dB@25KHz
Inter-modulation Rejection	≥60dB/ ≥65dB
Spurious Response Rejection	≥70dB
Rated Audio Response	+1-+3dB
Rated Audio Distortion	<5%
FM Hum&Noise	≥40dB@25KHz /≥45KHz @12.5KHz
Transmitter
RF Power	60W/25W/10W(VHF)
Frequency Modulation	11kΦF3E / 16kΦF3E
Modulation Distortion	<5%
FM Noise	≥36dB@25KHz /≥40KHz @12.5KHz
Adjacent Channel Power	≥60dB@12.5KHz /≥70KHz @25KHz
Audio Response	+1-+3dB
Audio Distortion	<5%

Each Set PACKAGE CONTAIN 1x TYT TH-9000 VHF 136-174Mhz Mobile Radio 1x Microphone 1x Mobile Mounting Bracket 1x DC Power Cable 1x A Pack Of Screw And Accessories 1x English Manual CY
